    Detailed Product Description
    Material: ITEQ FR4TG180 Layer: 8-layer
    Feature: ENGI Copper Thickness: 0.5oz Inner Layer / 1.0oz Outlayer
    Board Thickness: 1.6MM

    8layer ITEQ FR4TG180 Rigid HDI PCB Board With Immerion Gold Ni Au

    Key Specifications/Special Features:


    Layer : 8 Layers
    Base Material :  ITEQFR4 TG180
    Copper Thickness : 0.5oz inner layer /  1oz outlayer
    Board Thickness :   1.60mm

    Surface copper thickness : Maximum: 6/6oz / Minimum: 0.5/0.5oz

    Maximum board thickness : 6.0mm
    Minimum track space : 4/4, 3mil partial allowed
    Minimum size : 3 x 3mm
    Maximum size : 1000 x 1200mm


    Lead Time:



    Types



    (Max ㎡/month)

    Samples

    (days)

    Mass Production(days)
    New PO Repeat PO Urgent
    2layer 50000 sq.m/month 2-3 10-11 8-9 4
    4layer 5-6 11-12 9-11 5
    6layer 6-7 13-14 12-14 6
    8layer 7-8 16-18 14-15 7




    Main Export Markets:

    • Asia
    • Australasia
    • North America
    • Western Europe


    Advantages :


    •  Strict product liability, taking IPC-A-160 standard
    •  Engineering pretreatment before production
    •  Production process control (5Ms)
    •  100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC
    •  100% AOI inspection, including X-ray, 3D microscope and ICT
    •  High-voltage test, impedance control test
    •  Micro section, soldering capacity, thermal stress test, shocking test
    •  In-house PCB production
    •  No minimum order quantity and free sample
    •  Focus on low to medium volume production
    •  Quick and on-time delivery





    FAQ



    1. How do ACCPCB ensure quality?



    Our high quality standard is achieved with the following.

    1.1 The process is strictly controlled under ISO 9001:2008 standards.
    1.2 Extensive use of software in managing the production process
    1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
    1.4.Dedicated quality assurance team with failure case analysis process

    2. What kinds of boards can ACCPCB process?



    Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.


    3. What data are needed for PCB production?



    PCB Gerber files with RS-274-X format.


    4. What’s the typical process flow for multi-layer PCB?



    Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.


    5. How many types of surface finish ACCPCB can do?



    O-the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.


    6. What are the main factors which will affect the price of PCB?



    Material;
    Surface finish;

    Board thickness, Copper thickness;
    Technology difficulty;
    Different quality criteria;
    PCB characteristics;
    Payment terms;



    7. How to you make the impedance calculation?



    The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment.



    8layer ITEQ FR4TG180 Rigid HDI PCB Board With Immerion Gold Ni Au
