Interconnect Hdi Printed Circuit Boards High Density Precision for Artificial intelligence equipment

Interconnect Hdi Printed Circuit Boards High Density Precision for Artificial intelligence equipment

    • Interconnect Hdi Printed Circuit Boards High Density Precision for Artificial intelligence equipment
    • Interconnect Hdi Printed Circuit Boards High Density Precision for Artificial intelligence equipment
  • Interconnect Hdi Printed Circuit Boards High Density Precision for Artificial intelligence equipment

    Product Details:

    Place of Origin: China
    Brand Name: ACCPCB
    Certification: ISO, UL, SGS,TS16949
    Model Number: P1147

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PCS
    Price: Negotiable
    Packaging Details: Vacuum packing with desiccant
    Delivery Time: 15-20days
    Payment Terms: L/C / T/T / Western Union / Paypal
    Supply Ability: 25000SQ.M/PER MONTH
    Contact Now
    Detailed Product Description
    Material: ShengyiFR4TG150 Layer: 4 Layer
    Feature: Immersion Tin Copper Thickness: 2oz Inner Layer / 2.5oz Outlayer
    Board Thickness: 1.20MM

    Interconnect Hdi Printed Circuit Boards High Density Precision for Artificial intelligence equipment



    Key Specifications/Special Features:



    Number of layers : 4layer
    Base-material : Shengyi FR4TG150
    Thickness : 1.20 mm+/-10%
    Final-Cu : 70um
    Blind and buried via : Yes
    Min. Drill hole : 0.4mm
    Min. Line space : 0.6mm
    Min. Line width : 0.6mm
    Mech. treatment : Routing +v-cuting
    Surface treatment : Immersion tin
    Solder-mask : Red
    Legend-Print : white
    100% E-test : Yes



    Lead Time:

    Types



    (Max ㎡/month)

    Samples

    (days)

    Mass Production(days)
    New PO Repeat PO Urgent
    2layer 50000 sq.m/month 2-3 10-11 8-9 4
    4layer 5-6 11-12 9-11 5
    6layer 6-7 13-14 12-14 6
    8layer 7-8 16-18 14-15 7




    Main Export Markets:

    • Asia : Main 2-8layer
    • Australasia : 2--10layer
    • North America : 4layer over
    • Western Europe : 4--12layer


    Advantages :


    •  Strict product liability, taking IPC-A-160 standard
    •  Engineering pretreatment before production
    •  Production process control (5Ms)
    •  100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC
    •  100% AOI inspection, including X-ray, 3D microscope and ICT
    •  High-voltage test, impedance control test
    •  Micro section, soldering capacity, thermal stress test, shocking test
    •  In-house PCB production
    •  No minimum order quantity and free sample
    •  Focus on low to medium volume production
    •  Quick and on-time delivery







    FAQ



    1. How do ACCPCB ensure quality?



    Our high quality standard is achieved with the following.

    1.1 The process is strictly controlled under ISO 9001:2008 standards.
    1.2 Extensive use of software in managing the production process
    1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
    1.4.Dedicated quality assurance team with failure case analysis process

    2. What kinds of boards can ACCPCB process?



    Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.


    3. What data are needed for PCB production?



    PCB Gerber files with RS-274-X format.


    4. What’s the typical process flow for multi-layer PCB?



    Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.


    5. How many types of surface finish ACCPCB can do?



    O-the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.


    6. What are the main factors which will affect the price of PCB?



    Material;
    Surface finish;

    Board thickness, Copper thickness;
    Technology difficulty;
    Different quality criteria;
    PCB characteristics;
    Payment terms;



    7. How to you make the impedance calculation?



    The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment.
