Name: 1.60mm board thickness 1.2oz copper thickness PWB Circuit Board and HAL Lead Free
Brand: ACCPCB
SKU: S102112

Home Products PWB Circuit Board

1.60mm board thickness 1.2oz copper thickness PWB Circuit Board and HAL Lead Free

Product Details:

Place of Origin:	China
Brand Name:	ACCPCB
Certification:	ISO,SGS,TS16949
Model Number:	S102112

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Negotiable
Packaging Details:	Vacuum packing
Delivery Time:	3-5days
Payment Terms:	T/T ,Western Union,Paypal
Supply Ability:	50000SQ.M/Per Month

Contact Now

Detailed Product Description

Material:	ITEQ FR4	Count:	Double Sided
Surface Finish:	HASL LEAD FREE	Application:	Monitor Device
Solder Mask:	Blue,Green,black, Yellow, White Etc.	Copper Thickness:	1oz All Layer
Min. Hole Size:	8 Mil/6 Mil	Min. Line Spacing:	4mil
Min. Line Width:	4mil	Service:	Customized PCB
High Light:	1oz PWB Circuit Board , 8mil PWB Circuit Board , 6mil PWB Circuit Board

1.60mm board thickness 1.2oz copper thickness PWB Circuit Board and HAL Lead Free

Production description :

this board is double sided PCB it is used on led tube light production. PCB prototype,samll volum, middle and large volume are accepted. no MOQ request for new boards.

PCB Flow Chart.pdf

Key Specifications of led tub PCB board :

Production Types:	Rigid PCB lead free
Layer :	2 layer
Base Material :	ITEQ FR4
Copper Thickness :	1.2oz
Board Thickness :	1.60mm
Min. Finish Hole Size :	8 mil (0.20mm)
Min. Line Width :	4 mil
Min. Line Spacing :	4 mil
Surface Finishing :	ENIG,OSP,HASL lead free ,Immersion Gold,Gold Plating
Drilling hole tolerance:	+/-3 mil ( 0.075mm )
Min Outline tolerance :	+/-4 mil ( 0.10mm )
Working panel size :	max:1200mmX600mm (47'' X24'')
Outline profile:	Punching, Routing , CNC routing + V-cut
Solder mask :	LPI Solder mask, Peelable mask
Solder Mask Color :	Blue, black,yellow, matte green
Certificate :	UL, CQC, TS16949, ISO14000, ROHS
Silkscreen color :	White
Twist and Bow :	no more than 0.75 %

Products Application:

Our customized PCB is used in medical machinery field, aerospace field, automobile field, computer equipment, communication electronic equipment, military weapon system and so on.

1.60mm board thickness 1.2oz copper thickness PWB Circuit Board and HAL Lead Free 0

Technology Capability:

Item	Technical Parameters
Layers	1-28 Layers
Inner Layer Min Trace/Space	4/4 mil
Out Layer Min Trace,Space	4/4 mil
Inner Layer Max Copper	4 OZ
Out Layer Max Copper	4 OZ
Inner Layer Min Copper	1/3 oz
Out Layer Min Copper	1/3 oz
Min hole size	0.15 mm
Max.board thickness	6 mm
Min.board thickness	0.2mm
Max.board size	680*1200 mm
PTH Tolerance	+/-0.075mm
NPTH Tolerance	+/-0.05mm
Countersink Tolerance	+/-0.15mm
Board Thickness Tolerance	+/-10%
Min BGA	7mil
Min SMT	7*10 mil
Solder mask bridge	4 mil
Solder mask color	White,black,blue,green,yellow,red,etc
Legend color	White,black,yellow,gray,etc
Surface finish	HAL,OSP, Immersion Ni/Au ,Imm silver/SN,ENIG
Board materials	FR-4;high TG;HighCTI; halogen free; Aluminum Bsed PCB,high frequency(rogers,isola),copper -base PCB
Impedance control	+/-10%
Bow and twist	≤0.5

1.60mm board thickness 1.2oz copper thickness PWB Circuit Board and HAL Lead Free 1

FAQ :

1. What data are needed for PCB production?

PCB Gerber files with RS-274-X format.

2. What kinds of boards can ACCPCB process?

Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.

3. How do ACCPCB ensure quality?

Our high quality standard is achieved with the following.

1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process
