Name: Surface Mount 4 Layer FR4 1.5oz copper thickness Prototype PCB Board
Brand: ACCPCB
SKU: P10464

Home Products Prototype PCB Board

Surface Mount 4 Layer FR4 1.5oz copper thickness Prototype PCB Board

Product Details:

Place of Origin:	China
Brand Name:	ACCPCB
Certification:	ISO,SGS,TS16949
Model Number:	P10464

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	Negotiable
Packaging Details:	Vacuum packing
Delivery Time:	3-5days
Payment Terms:	T/T ,Western Union,Paypal
Supply Ability:	50000SQ.M/Per Month

Contact Now

Detailed Product Description

Material:	Fiberglass FR4	Count:	4 Layer
Surface Finish:	Immersion Gold	Usage:	Electronics Computers
Copper Thickness:	1.5oz	Silkscreen Color:	White Or On Your Request.
Type:	Electronic Board	Min. Line Width:	0.10mm
Color:	Matte Green	Min. Line Spacing:	4mil
High Light:	1.5oz Prototype PCB Board , FR4 1.5oz PCB , FR4 1.5oz Prototype Board

Surface Mount 4 Layer FR4 1.5oz copper thickness Prototype PCB Board

Production description :

this board is 4layer pcb. it is used for electronics compuers. we can accep PCB prototype,samll volum, middle and large volume. no MOQ request for new boards, for repeat order, just meet 3sq.m.

PCB Flow Chart.pdf

Key Specifications/Special Features:

Number of layers:	4 layer
Base material:	FR4
Copper thickness:	1.5 oz Cu in all layer
Thickness:	1.58 mm
Size:	200 x 100 mm
Cooper In holes:	min 20um
Surface finishing:	immerison gold
Solder mask:	Green
Legends:	White
Outline profile:	Routing,V-Groove, Beveling punch
Working panel size :	max:1200mmX600mm (47'' X24'')
Solder mask :	LPI Solder mask, Peelable mask
Solder Mask Color :	Blue, black,yellow, matte green,white
Twist and Bow :	no more than 0.75 %
Certificate :	UL, CQC, TS16949, ISO14000, ROHS

Products Application:

Our products are widely used in meter, medical, solar energy, mobile, communication, industrial control, power electronics,security, consuming, computer, automotive, aerospace, military and so on.

Surface Mount 4 Layer FR4 1.5oz copper thickness Prototype PCB Board 0

Technology Capability:

Item	Technical Parameters
Layers	1-28 Layers
Inner Layer Min Trace/Space	4/4 mil
Out Layer Min Trace,Space	4/4 mil
Inner Layer Max Copper	4 OZ
Out Layer Max Copper	4 OZ
Inner Layer Min Copper	1/3 oz
Out Layer Min Copper	1/3 oz
Min hole size	0.15 mm
Max.board thickness	6 mm
Min.board thickness	0.2mm
Max.board size	680*1200 mm
PTH Tolerance	+/-0.075mm
NPTH Tolerance	+/-0.05mm
Countersink Tolerance	+/-0.15mm
Board Thickness Tolerance	+/-10%
Min BGA	7mil
Min SMT	7*10 mil
Solder mask bridge	4 mil
Solder mask color	White,black,blue,green,yellow,red,etc
Legend color	White,black,yellow,gray,etc
Surface finish	HAL,OSP, Immersion Ni/Au ,Imm silver/SN,ENIG
Board materials	FR-4;high TG;HighCTI; halogen free; Aluminum Bsed PCB,high frequency(rogers,isola),copper -base PCB
Impedance control	+/-10%
Bow and twist	≤0.5

FAQ:

1. What kinds of boards can ACCPCB process?

Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.

2. What data are needed for PCB production?

PCB Gerber files with RS-274-X format.

3. What’s the typical process flow for multi-layer PCB?

Material cutting → Inner dry film → inner etching → Inner AOI → Multi-bond→ Layer stack up Pressing → Drilling → PTH → Panel Plating → Outer Dry Film → Pattern Plating → Outer etching → Outer AOI → Solder Mask → Component Mark → Surface finish → Routing → E/T → Visual Inspection.

4. How do ACCPCB ensure quality?

Our high quality standard is achieved with the following.

1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process
