Performance Indicator 1.60Mm Lead Free PCB Board With Green Solder Mask

Performance Indicator 1.60Mm Lead Free PCB Board With Green Solder Mask

Performance Indicator 1.60Mm Lead Free PCB Board With Green Solder Mask
Performance Indicator 1.60Mm Lead Free PCB Board With Green Solder Mask
Performance Indicator 1.60Mm Lead Free PCB Board With Green Solder Mask
Product Details:
Place of Origin: China
Brand Name: ACCPCB
Certification: ISO, UL, SGS,TS16949
Model Number: P1037
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Price: Negotiable
Packaging Details: Vacuum packing with desiccant
Delivery Time: 10-15days
Payment Terms: L/C, T/T, Western Union,Paypal
Supply Ability: 30000SQ.M/Per Month
Contact Now
Detailed Product Description
Material: FR4 Fiber Application: Inducator
Cooper Thickness: 1oz Each Layer Board Thickness: 1.60mm
Surface Finish: HAL Lead Free Feature: Rigid Circuit Boards
Copper Thickness: 1oz Or Customized Min. Line Width: 0.1 0mm
Min. Hole Size: 0.10mm Service: OEM Services Provided
High Light:

1.60Mm Lead Free PCB Board

,

1.60Mm Rigid Circuit Boards

,

1oz Lead Free PCB Board

Performance Indicator 1.60Mm Lead Free PCB Board With Green Solder Mask







Production description :



this board is 4layer rigid pcb. it is used on electronic indicator . all of our board are met UL, ISO9001, TS1694 certification etc.no MOQ request for new boards, for repeat order, just meet 3sq.m.



Key Specifications of single PCB board :



Production Types: Rigid PCB
Layer : 4Layer
Base Material : FR4 fiber
Copper Thickness : 1 oz
Board Thickness : 1.600mm
Min. Finish Hole Size : 8 mil (0.10mm)
Min. Line Width : 4 mil
Min. Line Spacing : 4 mil
Surface Finishing : HAL lead free
Drilling hole tolerance: +/-3 mil ( 0.075mm )
Min Outline tolerance : +/-4 mil ( 0.10mm )
Working panel size : max:1200mmX600mm (47'' X24'')
Outline profile: Punching, Routing , CNC routing + V-cut
Solder mask : LPI Solder mask, Peelable mask
Solder Mask Color : Blue, black,yellow, matte green
Certificate : UL, CQC, TS16949, ISO14000, ROHS
Silkscreen color : White
Twist and Bow :

no more than 0.75 %









Quality Goal:



Category Performance indicator Quality Goal

Delivery

Customer service rate 99.9%
Semi Finished product Process inspection pass rate 100%
Finished product FQA Rebate rate 0.1%
Scrapped 1L scrap rate 0.5%
2L scrap rate 1%
Multi Layer scrap rate 2%
Customers Customer complaint rate 0.8%
Customer return rate 0.5%
Customer satisfaction 99%











Product Application Field :
