Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver

Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver

Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver
Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver
Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver
Product Details:
Place of Origin: China
Brand Name: ACCPCB
Certification: ISO, UL, SGS,TS16949
Model Number: P1116128
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negotiable
Packaging Details: Vacuum packing with desiccant
Delivery Time: 10-12days
Payment Terms: L/C / T/T / Western Union / Paypal
Supply Ability: 30,000SQ.M/Per Month
Contact Now
Detailed Product Description
Material: Glass Fiber Epoxy Copper Clad Laminate Thickness: 1.60MM
Surface Finish: Immersion Silver Layer: 4L
Copper Thicknes:: 1.5 Oz In Each Layer PCB Standard: IPC-A-610 D
Type: OEM PCB,customized PCB Min Holes Size: 4mil
Min. Line Width: 4mil Impedance Value: 90ohm
Solder Mask Color: Green,yellow, Red, White, Black Etc. Application: CCTV Camera
High Light:

1.5 Oz Impedance Control PCB

,

Fiberglass Epoxy Impedance Control PCB

,

1.5 Oz Immersion Silver PCB

Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver





Production description :



this material is fiber glass epoxy. the impedance control value is 90 ohm. it is use for cctv camera. all of our PCB are met UL, TS 16949,ROHS, ISO Etc. certification. no MOQ request for new order. for repeat order, it has to meet 3sq.m.





Key Specifications of Impedance conrol board :



Production Types: Rigid impedance control PCB

Layer :

4 Layers

Material : fiber glass epoxy
Copper Thickness :  1oz in all layer
Board Thickness :  1.60mm
Min. Finish Hole Size :  8 mil  (0.10mm)
Min. Line Width :  4 mil
Min. Line Spacing :  4 mil
Surface Finishing : Immersion silver
Drilling hole tolerance: +/-3 mil    (  0.075mm )
Min Outline tolerance : +/-4 mil    (  0.10mm )
Working panel size :  max:1200mmX600mm (47'' X24'')
Outline profile: Punching,  routing
Solder mask : LPI Solder mask, Peelable mask
Solder Mask Color : Blue, black,yellow, matte green
Certificate : UL, CQC, TS16949, ISO14000, ROHS
Silkscreen color : White
Twist and Bow :  no more than 0.75 %





PCB Flow Chart.pdf



Products Application:



Our products are widely used in meter, medical, solar energy, mobile, communication, industrial control, power electronics,security, consuming, computer, automotive, aerospace, military and so on.



Rigid PCB Technical Capability:



 Items                                      Technical Capability
Layers 1-28 layers Min. line width/space 4mil

Max.board size (single&doule

sided)

600*1200mm Min.annular ring width: vias 3mil
Surface finish

HAL lead free,gold flash

Immersion silver,Immersion gold ,Immersion Sn,

hard gold,OSP,ect

Min.board thickness(multilayer) 4layers:0.4mm;
6layers:0.6mm;
8layers:1.0mm;
10layers:1.20mm
Board materials

FR-4; high Tg; high CTI; halogen free; high frequency(rogers,taconic,

PTFE,nelcon,

ISOLA,polyclad 370 HR); heavy copper,

Metal base clade laminate

Plating thickness (Technique:

Immersion Ni/Au)

Plating type: Imm Ni, Min./Max thickness:100/150U'' Plating type: Imm Au, Min./Max thickness:2/4U''
Impedance control ± 10%

Distance between

line to board edge

Outline: 0.2mm

V-CUT: 0.4mm

Base copper thickness(Inner

and outer layer)

Min. thickness: 0.5 OZ Max.thickness: 6OZ Min.hole size(board thickness ≥2mm) Aspect ratio≤16
Finished copper thickness Outer layers:
Min.thickness 1 OZ,
Max.thickness 10 OZ
Inner layers:
Min.thickness :0.5OZ,
Max.thickness : 6 OZ
Max.board thickness(single&doule sided) 3.20mm



Advantages:


• Strict product liability, taking IPC-A-160 standard
• Engineering pretreatment before production
• Production process control (5Ms)
• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC
• 100% AOI inspection, including X-ray, 3D microscope and ICT
• High-voltage test, impedance control test
• Micro section, soldering capacity, thermal stress test, shocking test
• In-house PCB production
• No minimum order quantity and free sample
• Focus on low to medium volume production
• Quick and on-time delivery






Fiberglass Epoxy 1.5 Oz Impedance Control PCB With Immersion Silver 0






FAQ :


1. What kinds of boards can ACCPCB process?



Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.


2. What data are needed for PCB production?



PCB Gerber files with RS-274-X format.
