NYFR4 TG150 High TG PCB rigid PCB and Vias on the pad filled with resin For Digital Device

NYFR4 TG150 High TG PCB rigid PCB and Vias on the pad filled with resin For Digital Device

NYFR4 TG150 High TG PCB rigid PCB and Vias on the pad filled with resin For Digital Device
NYFR4 TG150 High TG PCB rigid PCB and Vias on the pad filled with resin For Digital Device
NYFR4 TG150 High TG PCB rigid PCB and Vias on the pad filled with resin For Digital Device
Product Details:
Place of Origin: China
Brand Name: ACCPCB
Certification: ISO, UL, SGS,TS16949
Model Number: P1238
Payment & Shipping Terms:
Minimum Order Quantity: 20PCS
Price: Negotiable
Packaging Details: Vacuum packing with desiccant
Delivery Time: 8-15 Days
Payment Terms: L/C / D/A / T/T / Western Union
Supply Ability: 30,000SQ.M/PER MONTH
Contact Now
Detailed Product Description
Material: FR4 TG150 Thickness: 1.20mm
Size: 90mmX230mm Number Of Layers: 4layer
Min. Line Spacing: 0.1mm / 4mil Service: One-stop Turnkey Service,competitive Price
High Light:

computer circuit board

,

lcd display pcb

NYFR4 TG150 High TG PCB rigid PCB and Vias on the pad filled with resin For Digital Device



Production description :

this board is 4layer PCB it is used for digital device. PCB prototype,samll volum, middle and large volume are accepted. no MOQ request for new boards. all pcb are met UL, ISO9001, TS16949, ROHS etc.



Key Specifications/Special Features :

Layer : 4Layers
Base Material : ITEQ FR4TG150
Vias on pads : Vias on the pad filled with resin
Board Thickness : 1.20mm
Min. Hole Size : 6mil / 0.15mm
Min. Line Width : 4 / 4 mil
Min. Line Spacing : 4 / 4mil
Surface Finishing : Immersion Tin
Solder Mask Color : Green
Outline : Routing,V-Groove
Silkscreen color : White
Certificate : UL, CQC, TS16949, ISO14000, ROHS



Application:

Industril Control System
Power Supply
LED drive, LED Lighting
Communication Device
automotive electronics
Security Electronics
Household Control
Digital Appliances
Frequency converter
Medical Device



Quality assurance :

Every production process has a special person to test to ensure quality, AOI and E-testing.

Have professional engineers to check the quality

All products have passed CE, FCC, ROHS and other certifications



Shipping Information:
FOB Port : Hong Kong / Shenzhen                                     Lead Time : 8 - 15 days
HTS Code : 8534.00.10                                    Dimensions per Carton : 37X27X22mm
Weight Per Carton : 20 Kilograms


FAQ :

1. What kinds of boards can ACCPCB process?

   Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.


2. What data are needed for PCB production?

    PCB Gerber files with RS-274-X format.



3. How many types of surface finish ACCPCB can do?

    the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.


4. What are the main factors which will affect the price of PCB?

      Material;
     Surface finish;

     Board thickness, Copper thickness;
     Technology difficulty;
     Different quality criteria;
     PCB characteristics;
     Payment terms;



5. How do ACCPCB ensure quality?

Our high quality standard is achieved with the following.

1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process



6. How to you make the impedance calculation?

  The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment.
