1.50mm thickness Lead Free PCB Fabrication wioth 100X90mm for Game Driver

1.50mm thickness Lead Free PCB Fabrication wioth 100X90mm for Game Driver

1.50mm thickness Lead Free PCB Fabrication wioth 100X90mm for Game Driver
1.50mm thickness Lead Free PCB Fabrication wioth 100X90mm for Game Driver
1.50mm thickness Lead Free PCB Fabrication wioth 100X90mm for Game Driver
Product Details:
Place of Origin: China
Brand Name: ACCPCB
Certification: ISO, UL, SGS,TS16949
Model Number: S10182
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiable
Packaging Details: Vacuum packing with desiccant
Delivery Time: 10days
Payment Terms: L/C / D/P / T/T / Western Union / Paypal
Supply Ability: 30,000SQ.M/Month
Contact Now
Detailed Product Description
Material: FR4 Tg150 Thickness: 1.20mm
Surface Finish: ENIG Min. Hole Size: 0.15MM
Copper Thickness: 0.5-6oz Product Name: 94v0 PCB
High Light:

enig rohs pcb

,

halogen free pcb

ENIG PCB Board 1.50 mm Board Thickness With ENIG For Game Driver



Production description :

this board is 6layer PCB it is used on game driver. PCB prototype,samll volum, middle and large volume are accepted. no MOQ request for new boards.



Production Feature:

Layer : 6 Layers
Base Material : FR4
Copper Thickness : 1oz inner Layer, 1oz out layer
Board Thickness : 1.50 mm
Surface Finish : ENIG
Min. Hole Size : 6 mil / 0.15mm
Min. Line Width : 4/4 mil / 0.10/0.10 mm
Min. Line Spacing : 4/4mil / 0.10/0.10mm
Application : Game Driver
Certification : ISO9001, UL, ROHS,TS16949



Quality assurance :

Every production process has a special person to test to ensure quality

Have professional engineers to check the quality

All products have passed CE, FCC, ROHS and other certifications



Advantages :
▪ No MOQ, 14 years of PCB turnkey services
▪ Quick turn, prototype, low & medium & high volume
▪ OEM services provide
▪ ISO 9001-, ISO 14001-, ISO/TS16949, ISO 13485, IATF16949, OHSAS18001 certified
▪ 100% E-test, visual, AOI inspection, including X-ray, 3D microscope
▪ Fast response within 24 hours



Technology Capability:

Item Technical Parameters
Layers 1-28 Layers
Inner Layer Min Trace/Space 4/4 mil
Out Layer Min Trace,Space 4/4 mil
Inner Layer Max Copper 4 OZ
Out Layer Max Copper 4 OZ
Inner Layer Min Copper 1/3 oz
Out Layer Min Copper 1/3 oz
Min hole size 0.15 mm
Max.board thickness 6 mm
Min.board thickness 0.2mm
Max.board size 680*1200 mm
PTH Tolerance +/-0.075mm
NPTH Tolerance +/-0.05mm
Countersink Tolerance +/-0.15mm
Board Thickness Tolerance +/-10%
Min BGA 7mil
Min SMT 7*10 mil
Solder mask bridge 4 mil
Solder mask color White,black,blue,green,yellow,red,etc
Legend color White,black,yellow,gray,etc
Surface finish HAL,OSP, Immersion Ni/Au ,Imm silver/SN,ENIG
Board materials FR-4;high TG;HighCTI; halogen free; Aluminum Bsed PCB,high frequency(rogers,isola),copper -base PCB
Impedance control +/-10%
Bow and twist ≤0.5



FAQ :

1. How do ACCPCB ensure quality?

    Our high quality standard is achieved with the following.

1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 State-of-art testing equipments and tools. E.g. Flying Probe,e-Testing, X-ray Inspection, AOI (Automated Optical Inspector) .
1.4.Dedicated quality assurance team with failure case analysis process

2. What kinds of boards can ACCPCB process?

   Common FR4, high-TG and halogen-free boards, Rogers, Arlon, Telfon, aluminum/copper-based boards, PI, etc.


3. What data are needed for PCB production?

    PCB Gerber files with RS-274-X format.


4. How many types of surface finish ACCPCB can do?

     the leader has the full series of surface finish, such as: ENIG, OSP, LF-HASL, gold plating (soft/hard), immersion silver, Tin, silver plating, immersion tin plating, carbon ink and etc. .. OSP, ENIG, OSP + ENIG commonly used on the HDI, we usually recommend that you use a client or OSP OSP + ENIG if BGA PAD size less than 0.3 mm.



5. How to you make the impedance calculation?

   The impedance control system is done using some test coupons, the SI6000 soft and the CITS 500s equipment
